Sunday, 28 March 2021

SPOTTED CLEANER SHRIMP

"Wash that for you, sir?" If you were a fish living in the warm turquoise waters off the coast of Bonaire in the southern Caribbean Sea, you may not hear those words, but you'd see the shrimp sign language equivalent. It seems Periclimenes yucatanicus or the Spotted Cleaner Shrimp are doing a booming business in the local reefs by setting up a Fish Wash service.

That's right, a Fish Wash. You'd be hard-pressed to find a terrestrial Molly Maid with two opposable thumbs as studious and hardworking as this wee marine beauty. You'll find them each day cleaning and snacking on a host of parasites. As many as twenty to thirty shrimp gather together to assemble a  highly-efficient marine cleaning station. They're even open to partnerships and mergers, partnering up with Cleaner Wrasse, or cleaner fish, for larger, high-end clients.

Spotted cleaner shrimp are about 2.5 cm long and have a delightful transparent body with telltale white and brown spots. Their legs, or chelae, are striped in purple, white and red. They live about 24 metres (or 79 ft) down on the seafloor in many of our planet's most beautiful waters. Aside from the Caribbean, they also enjoy the waters off of the Bahamas, southern Florida, Panama and Columbia. They are carnivorous crustaceans in the family, Palaemonidae.

This quiet marine mogul is turning out to be one of the ocean's top entrepreneurs. Keeping its host and diet clean and green, the spotted shrimp hooks up with the locals, in this case, local sea anemones and sets up a fish wash. Picture a car wash but without the noise and teenage boys. The signage posted is the shrimps' natural colouring which attracts fish from around the reefs. They sway back and forth to indicate that they are open for business.

Wash on, wash off.

Once within reach, the shrimp cleans the surface of the fish, giving the fish a buff and the shrimp its daily feed. This is good news for the shrimp, especially this time of year as they breed and brood their eggs in summer.

After hatching, the larvae pass through a series of sadly, tasty planktonic stages before setting up a fish wash of their own. These cuties form a solid base for the oceanic food chain. Once they are older, they gain some protection from being eaten by their clients by a special signalling system that essentially shouts, "just here IN cooperation not as food." Here's to Periclimenes for keeping up the family business.

Saturday, 27 March 2021

ICHTHYOSAUR BASIOCCIPITAL BONE AND TELEOST FISH

Ichthyosaur Basioccipital Bone / Liam Langley
A very exciting find of an Ichthyosaur basioccipital bone. This is the bone next to the skull that connected to the vertebrae. He found this in situ so not very water warn as you might expect. This lovely bone was found by the deeply awesome Liam Langley on the Yorkshire Coast.

Ichthyosaurs became extinct during the Upper Cretaceous, about 30 million years before the K/T extinction event. There was an ocean anoxic event at the Cenomanian–Turonian stage boundary. The deeper layers of the seas became anoxic and poisoned by hydrogen sulphide. As life died off in the lower (benthos) levels of the sea, so did the predators at the top of the food chain. The last pliosaurs and ichthyosaurs became extinct.

Ichthyosaurs had been dwindling in numbers for some time; they were no longer the force they once were in the Upper Triassic and Lower Jurassic. By the middle Jurassic, it was thought they all belonged to the single clade, the Ophthalmosauridae. By the Cretaceous, it was thought that only three genera survived. For the last 50+ years, it has been thought that only one genus, Platypterygius, was known at the time of the anoxic event in the Upper Cretaceous.

Ichthyosaur Basioccipital Bone / Liam Langley
There was still diversity in ichthyosaurs a few million years before the extinction event. They may have survived right up to the extinction event. Ichthyosaurs had declined from their peak.

By the Cretaceous, they certainly had more competitors than in the Triassic and more elusive prey. The adaptive radiation of teleost fish meant their new prey was fast swimming and highly evasive.

The difference between teleosts and other bony fish lies mainly in their jawbones; teleosts have a movable premaxilla and corresponding modifications in the jaw musculature which make it possible for them to protrude their jaws outwards from the mouth.

This is of great advantage, enabling them to grab prey and draw it into the mouth. In more derived teleosts, the enlarged premaxilla is the main tooth-bearing bone, and the maxilla, which is attached to the lower jaw, acts as a lever, pushing and pulling the premaxilla as the mouth is opened and closed. Other bones further back in the mouth serve to grind and swallow food.

Another difference is that the upper and lower lobes of the tail (caudal) fin are about equal in size. The spine ends at the caudal peduncle, distinguishing this group from other fish in which the spine extends into the upper lobe of the tail fin.

The most basal of the living teleosts are the Elopomorpha, eels and their allies, and the Osteoglossomorpha, those whacky elephantfish and their friends. There are over 800 species of elopomorphs; each with thin leaf-shaped larvae known as leptocephali specialized for a marine environment.

Among the elopomorphs, eels have elongated bodies with lost pelvic girdles and ribs and fused elements in the upper jaw. The 200 species of osteoglossomorphs are defined by a bony element in the tongue. This element has a basibranchial behind it, and both structures have large teeth that are paired with the teeth on the parasphenoid in the roof of the mouth.

The clade Otocephala includes the Clupeiformes, tasty herrings, and Ostariophysi  — carp, catfish and their friends. Clupeiformes are made up of 350 living species of herring and herring-like fish. This group is characterized by an unusual abdominal scute and a different arrangement of the hypurals. In most species, the swim bladder extends to the braincase and plays a role in hearing. Ostariophysi, which includes most freshwater fishes, has developed some unique adaptations.

One is the Weberian apparatus, an arrangement of bones, called Weberian ossicles, connecting the swim bladder to the inner ear. This enhances their hearing, as sound waves make the bladder vibrate, and the bones transport the vibrations to the inner ear. They also have a chemical alarm system; when a fish is injured, the warning substance gets in the water, alarming nearby fish. Excellent for the predatory fish, less so for their poor injured brethren.

The teleosts included fast-swimming predatory fish, which would have been competing for similar food resources to our ichthyosaur friends. Had they complained about the teleosts they would have been deeply aghast to know what was coming next — big, hungry mosasaurs. The ichthyosaurs and pliosaurs were replaced in the marine ecology by the giant mosasaurs. The mosasaurs were probably ambush-hunters, whose sit-and-wait strategy apparently proved most successful. So, teleost fish, the ocean anoxic event and the rise of mosasaurs all contributed to the end of the ichthyosaurs.

Photos 1-2: By the awesome Liam Langley
Image 3: By Sir Francis Day - Fauna of British India, Fishes (www.archive.org), Public Domain, https://commons.wikimedia.org/w/index.php?curid=1919094

Friday, 26 March 2021

LOPHIIFORMES: ANGLERFISH

Humpback Anglerfish, Melanocetus johnsonii
The festive lassie you see here with her toothy grin and solo birthday-candle-style light is an Anglerfish.

They are bony fish of the teleost order Lophiiformes (Garman, 1899) and one of the most interesting, intriguing yet creepy, species on this planet.

There are over 200 species of anglerfish, most living in the pitch-black depths of the Atlantic and Antarctic oceans. They always look to be celebrating a birthday of some kind, albeit solo. This party is happening deep in our oceans right now and for those that join in, I hope they like it rough. The wee candle you see on her forehead is a photophore, a tiny bit of luminous dorsal spine. Many of our sea dwellers have photophores. We see them in glowing around the eyes of some cephalopods.

These light organs can be a simple grouping of photogenic cells or more complex with light reflectors, lenses, colour filters able to adjust the intensity or angular distribution of the light they produce. Some species have adapted their photophores to avoid being eaten, in others, it's an invitation to lunch but not in the traditional sense of that invite. In the anglerfish' world, it's dead sexy, an adaptation used to attract prey and mates alike, sometimes at the same time.

Deep in the murky depths of the Atlantic and Antarctic oceans, hopeful female anglerfish light up their sexy lures. When a male latches onto this tasty bit of flesh, he fuses himself totally.

He might be one of several potential mates. Each will take a turn getting close to her to see if she's the one. For her, it's not much of a choice. She's not picky, just hungry.

Mating is a tough business down in the depths. A friend asked if anglerfish mate for life. Well, yes... yes, indeed they do. Lure. Feed. Mate. Repeat. Once connected, the attachment is permanent. Her body absorbs his over time until all that's left are his testes. While unusual, it is only one of many weird and whacky ways our fishy friends communicate, entice, hunt and creatively survive and thrive. Ah, this planet has some evolutionary adaptations that are enough to break your brain. Anglerfish are definitely in with that lot.


Thursday, 25 March 2021

VICTORASPIS LONGCORNUALIS

This lovely specimen, showing both the positive and negative of the fossil, is an armoured agnatha jawless bony fish, Victoraspis longicornualis, from Lower Devonian deposits of Podolia, Ukraine.

Podolia is a historic region in Eastern Europe in the west-central and south-western parts of the Ukraine. This area has had human inhabitants since at least the beginning of the Neolithic period.

Herodotus mentions it as the seat of the Graeco-Scythian Alazones and possibly Scythian Neuri. Subsequently, the Dacians and the Getae arrived. The Romans left traces of their rule in Trajan's Wall, which stretches through the modern districts of Kamianets-Podilskyi, Nova Ushytsia and Khmelnytskyi.

During the Great Migration Period, many nationalities passed through this territory or settled within it for some time, leaving numerous traces in archaeological remains. Nestor in the Primary Chronicle mentions four apparently Slavic tribes: the Buzhans and Dulebes along the Southern Bug River, and the Tivertsi and Ulichs along the Dniester. The Avars invaded in the 7th century. The Bolokhoveni occupied the same territory in Early Medieval times but they were mentioned in chronicles only until the 14th century.

And, as you can see here, it boasts some wonderful Devonian deposits. Victoraspis longicornualis was named by Anders Carlsson and Henning Bloom back in 2008. The new osteostracan genus and species were described based on material from Rakovets' present-day Ukraine. This new taxon shares characteristics with the two genera Stensiopelta (Denison, 1951) and Zychaspis (Javier, 1985).

Agnatha is a superclass of vertebrates. This fellow looks quite different from our modern Agnatha, which includes lamprey and hagfish. Ironically, hagfish are vertebrates that do not have vertebrae. Sometime in their evolution, they lost them as they adapted to their environment. Photo: Fossilero Fisherman

Wednesday, 24 March 2021

MANATEES OF TEXAS

Manatees do not live year-round in Texas, but these gentle sea cows are known to occasionally visit, swimming in for a 'summer vacation' and returning to warmer waters for the winter. New research has found fossil evidence for manatees along the Texas coast dating back to the most recent ice age.

The discovery raises questions about whether manatees have been visiting for thousands of years, or if an ancient population of ice age manatees once called Texas home somewhere between 11,000 and 240,000 years ago.

The findings were published in Palaeontologia Electronica by lead author Christopher Bell, a professor at the UT Jackson School of Geosciences with co-authors Sam Houston State University Natural History Collections curator William Godwin and SHSU alumna Kelsey Jenkins — now a graduate student at Yale University — and SHSU Professor Patrick Lewis.

The eight fossils described in the paper include manatee jawbones and rib fragments from the Pleistocene, the geological epoch of the last ice age. Most of the bones were collected from McFaddin Beach near Port Arthur and Caplen Beach near Galveston during the past 50 years by amateur fossil collectors who donated their finds to the SHSU collections.

The Jackson Museum of Earth History at UT holds two of the specimens. A lower jawbone fossil, which was donated to the SHSU collections by amateur collector Joe Liggio, jumpstarted the research.

Manatee jawbones have a distinct S-shaped curve that immediately caught Godwin's eye. But Godwin said he was met with scepticism when he sought other manatee fossils for comparison. He recalls reaching out to a fossil seller who told him point-blank "there are no Pleistocene manatees in Texas."

But an examination of the fossils by Bell and Lewis proved otherwise. The bones belonged to the same species of manatee that visits the Texas coast today, Trichechus manatus. An upper jawbone donated by U.S. Rep. Brian Babin was found to belong to an extinct form of the manatee, Trichechus manatus bakerorum.

The age of the manatee fossils is based on their association with better-known ice age fossils and paleo-Indian artefacts that have been found on the same beaches.

It's assumed that the cooler ice age climate would have made Texas waters even less hospitable to manatees than they are today. But the fact that manatees were in Texas — whether as visitors or residents — raises questions about the ancient environment and ancient manatees. The Texas coast stretched much farther into the Gulf of Mexico and hosted wider river outlets during the ice age than it does today. Either the coastal climate was warmer than is generally thought, or ice age manatees were more resilient to cooler temperatures than manatees of today.

Subsurface imaging of the now flooded modern continental shelf reveals both a greater number of coastal embayments and the presence of significantly wider channels during ice age times.

If there was a population of ice age manatees in Texas, it's plausible that they would have ridden out winters in these warmer river outlets similar to how they do today in Florida and Mexico.

Reference: Christopher Bell, William Godwin, Kelsey Jenkins, Patrick Lewis. First fossil manatees in Texas: Trichechus manatus bakerorum in the Pleistocene fauna from beach deposits along the Texas Coast of the Gulf of Mexico. Palaeontologia Electronica, 2020; DOI: 10.26879/1006

Tuesday, 23 March 2021

DUGONGIDAE: STELLAR SEA COW

One of the most delightful creatures to ever grace this planet is the dugong — a species of sea cow found throughout the warm latitudes of the Indian and western Pacific Oceans.

It is one of four living species of the order Sirenia, which also includes three species of manatees — their large, fully aquatic, mostly herbivorous marine mammal cousins.

The closest living relatives of sirenians are elephants. Manatees evolved from the same land animals as elephants over 50 million years ago. If not for natural selection, we might have a much more diverse showing of the Sirenia as their fossil lineage shows a much more diverse group of sirenians back in the Eocene than we have today. It is the only living representative of the once-diverse family Dugongidae; its closest modern relative, Steller's sea cow, was hunted to extinction in the 18th century.

While only one species of the dugong is alive today – a second, the Steller's sea cow only left this Earth a few years ago. Sadly, it was hunted to extinction within 27 years of its discovery – about 30 species have been recovered in the fossil record

The first appearance of sirenians in the fossil record was during the early Eocene, and by the late Eocene, sirenians had significantly diversified. Inhabitants of rivers, estuaries, and nearshore marine waters, they were able to spread rapidly.

The most primitive sirenian known to date, Prorastomus, was found in Jamaica, not the Old World; however, more recently the contemporary Sobrarbesiren has been recovered from Spain. The first known quadrupedal sirenian was Pezosiren from the early Eocene. The earliest known sea cows, of the families Prorastomidae and Protosirenidae, are both confined to the Eocene and were about the size of a pig, four-legged amphibious creatures. By the time the Eocene drew to a close, the Dugongidae had arrived; sirenians had acquired their familiar fully aquatic streamlined body with flipper-like front legs with no hind limbs, powerful tail with horizontal caudal fin, with up and down movements which move them through the water, like cetaceans.

The last of the sirenian families to appear, Trichechidae, apparently arose from early dugongids in the late Eocene or early Oligocene. The current fossil record documents all major stages in hindlimb and pelvic reduction to the extreme reduction in the modern manatee pelvis, providing an example of dramatic morphological change among fossil vertebrates.

Since sirenians first evolved, they have been herbivores, depending on seagrasses and aquatic angiosperms, tasty flowering plants of the sea, for food. To the present, almost all have remained tropical (with the notable exception of Steller's Sea Cow), marine, and angiosperm consumers. Sea cows are shallow divers with large lungs. They have heavy skeletons to help them stay submerged; the bones are pachyostotic (swollen) and osteosclerotic (dense), especially the ribs which are often found as fossils.

Eocene sirenians, like Mesozoic mammals but in contrast to other Cenozoic ones, have five instead of four premolars, giving them a 3.1.5.3 dental formula. Whether this condition is truly primitive retention in sirenians is still under debate.

Although cheek teeth are relied on for identifying species in other mammals, they do not vary to a significant degree among sirenians in their morphology but are almost always low-crowned —brachyodont — with two rows of large, rounded cusps — bunobilophodont. The most easily identifiable parts of sirenian skeletons are the skull and mandible, especially the frontal and other skull bones. With the exception of a pair of tusk-like first upper incisors present in most species, front teeth — incisors and canines — are lacking in all, except the earliest sirenians.

Monday, 22 March 2021

ICHTHYOSAURS, SHARKS AND BLUBBER

We've learned much about the mighty ichthyosaur since first discovering their bones in Wales back in 1699. That's over three hundred years of knowledge.

We have classified them as an extinct order of marine reptiles from the Mesozoic era. We know that they were visibly dolphin-like in appearance and share some other qualities as well. They were warm-blooded, used their colouration as camouflage and had insulating blubber to keep them warm.

Ichthyosaurs are interesting because they have many traits in common with dolphins, but are not at all closely related to those sea-dwelling mammals. We aren't exactly sure of their biology either. They have many features in common with living marine reptiles like sea turtles, but we know from the fossil record that they gave live birth, which is associated with warm-bloodedness. This study reveals some of those biological mysteries.

We find their fossil remains in outcrops spanning the mid-Cretaceous to the earliest Triassic. As we look through the fossils, we see a slow evolution in body design moving towards that enjoyed by dolphins and tuna by the Upper Triassic, albeit with a narrower, more pointed snout.

Johan Lindgren, Associate Professor at Sweden's Lund University and lead author on the paper,  described the 180 million-year-old specimen, Stenopterygius, from outcrops in the Holzmaden quarry in Germany.

Both the body outline and remnants of internal organs are clearly visible in the specimen. Remarkably, the fossil is so well-preserved that it is possible to observe individual cellular layers within its skin.

Stenopterygius quadriscissus
Researchers identified cell-like microstructures containing pigment organelles on the surface of the fossil.

This ancient skin revealed a feature we recognized from marine dwelling animals, the ability to change colour, providing camouflage from potential predators. They also found traces of what might have been the animal's liver.

When they put some of the tissue through chemical analysis, it was consistent with what we'd look for in adipose tissue or blubber. Not surprising as dolphins today use blubber for buoyancy and to help to thermally insulate for thermal regulation in cold seas. It's a highly useful adaptation and one that led me to wonder what other vertebrates might use blubber or some other adaptation to maintain a warmer body temperature independent of icy cold conditions.

Today, blubber is an important part of the anatomy of seals, walruses and whales. It covers the core of their bodies, storing energy, insulating them from cold seas and providing extra buoyancy.

A rather fetching Walrus, Odobenus rosmarus
Fat and blubber are not the same. The main differences are their consistency and blood supply —  blubber contains many more blood vessels than fat, and is far denser because it's made up of a mix of collagen fibres and lipids.

Blubber layers can be incredibly thick. Walruses deposit most of their body fat into a thick layer of blubber — a layer of fat reinforced by fibrous connective tissue that lies just below the skin of most marine mammals.

This blubber layer insulates the walrus and streamlines its body. It also functions as an energy reserve. Blubber covers the core of their bodies but does not grace their fins, flippers and flukes.

Not all marine animals need blubber. Our cold-blooded marine friends: sharks, crabs, fish, are able to let their body temperatures dropdown to very chilly levels, some as low as 36 degrees Fahrenheit.

They have a few tricks up their sleeves to make this happen. Sharks have evolved specialized physiology to keep their metabolic rate high and their hearts are able to contract in the icy depths because of a special protein. These adaptations allow sharks to enjoy a wide range of habitats and follow their food from warm tropical seas to the icy waters of the North Pacific.

Gray Shark, Carcharhinus amblyrhynchos
With the advent of genetics, we've now learned that the Great White Shark’s genetic code and many of the proteins they use to control metabolism are more closely related to humans than zebrafish, the quintessential fish model.

In a very cool bit of science, researchers sequenced a shark's heart transcriptome – the messenger molecules produced from the shark’s genome, including those active in making proteins. Then they categorized the proteins based on their functions.

What they found that the proportions of white shark proteins in many categories matched humans more closely than zebrafish. Of particular interest was that white shark had a closer match to humans for proteins involved in metabolism. Great White Sharks have a rare trait in fish called regional endothermy. This allows them to keep the body temperature of some of their organs warmer than the ambient water — a highly useful trait for fast swimming, digestion and hunting in colder waters.

References and additional reading:

Fancy a read? Check out the work by Michael Stanhope, professor of evolutionary genomics at Cornell’s College of Veterinary Medicine, and scientists at the Save Our Seas Shark Research Center at Nova Southeastern University (NSU). He published the shark genetic study in the November 2013 issue of BMC Genomics. It lays the foundation for genomic exploration of sharks and vastly expands genetic tools for their conservation.

Johan Lindgren, Peter Sjövall, Volker Thiel, Wenxia Zheng, Shosuke Ito, Kazumasa Wakamatsu, Rolf Hauff, Benjamin P. Kear, Anders Engdahl, Carl Alwmark, Mats E. Eriksson, Martin Jarenmark, Sven Sachs, Per E. Ahlberg, Federica Marone, Takeo Kuriyama, Ola Gustafsson, Per Malmberg, Aurélien Thomen, Irene Rodríguez-Meizoso, Per Uvdal, Makoto Ojika, Mary H. Schweitzer. Soft-tissue evidence for homeothermy and crypsis in a Jurassic ichthyosaur. Nature, 2018; DOI: 10.1038/s41586-018-0775-x

North Carolina State University. (2018, December 5). Soft tissue shows Jurassic ichthyosaur was warm-blooded, had blubber and camouflage. ScienceDaily. Retrieved September 7, 2019, from www.sciencedaily.com/releases/2018/12/181205134118.htm

Photo: By Haplochromis - Own work, CC BY-SA 3.0, https://commons.wikimedia.org/w/index.php?curid=5825284

Sunday, 21 March 2021

OF LAND AND SEA

Our dear penguins, seals, sea lions, walruses, whales, crocodiles and sea turtles were once entirely terrestrial. Yes, they lived mostly or entirely on land.

Many of these once land-dwelling animals returned to the sea throughout evolutionary history. We have beautifully documented cases from amphibians, reptiles, birds and mammals from over 30 different lineages over the past 250 million years.

Some dipped a toe or two into freshwater ponds, but make no mistake, they were terrestrial. Each of these animals had ancestors that tried out the sea and decided to stay. They evolved and employed a variety of adaptations to meet their new saltwater challenges. Some adapted legs as fins, others became more streamlined, and still, others developed specialized organs to extract dissolved oxygen from the water through their skin or gills. The permutations are endless.

Returning to the sea comes with a whole host of benefits but some serious challenges as well. Life at sea is very different from life on land. Water is denser than air, impacting how an animal moves, sees and hears. More importantly, it impacts an air-breathing animal's movement on a pretty frequent basis. If you need air and haven't evolved gills, you need to surface frequently. Keeping your body temperature at a homeostatic level is also a challenge as water conducts heat much better than air. Even with all of these challenges, the lure of additional food sources and freedom of movement kept those who tried the sea in the sea and they evolved accordingly.

Most major animal groups appear for the first time in the fossil record half a billion years ago. We call this flourishing of species the Cambrian Explosion. While this was a hugely intense period of species radiation, the evolutionary origins of animals are likely to be significantly older. About 700 million years ago the Earth was covered in ice and snow. This was an ice age so intense we refer to this time in our ancient history as Snowball Earth. Once that ice receded, it exposed rocks that contained a variety of weird and wonderful fossils that speak to ancient animals that are only now being studied.

Dr Frankie Dunn, a palaeontologist and an Early Career Research Fellow at the Oxford University Museum of Natural History and Merton College is one of the folks who are examining this early history of some of our first animals. Her research focuses on the origin and early evolution of animals and particularly on the fossil record of the late Ediacaran Period (570 – 540 million years ago).  Dr Dunn's research is exploring ancient species like the long-extinct Rangeomorpha to help understand how animal body plans evolved in deep time well before the divergence of the extant (living) animal lineages.

Andy Temple (bless him) sent me a link for an online talk Dr Dunn is giving, The Chronicles of Charnia, Wed, June 17th at 7PM. She's based in Oxford so adjust your timezone accordingly. The talk is free but booking is required. Here's the link: https://event.webinarjam.com/register/59/xyy07flg

This is an interesting article from Alicia Ault writing for the Smithsonian who interviewed Nick Pysenson and Neil Kelley about some of their research that touches on this area. They published a paper on it in the journal Science. Here's the link: https://science.sciencemag.org/content/348/6232/aaa3716

And Ault's work is definitely worth a read: https://www.smithsonianmag.com/smithsonian-institution/take-deep-dive-reasons-land-animals-moved-seas-180955007/

Saturday, 20 March 2021

HUMPBACK WHALES: MEGAPTERA NOVAENGLIAE

Humpback Whales, Megaptera novaeangliae, are a species of baleen whale. These are whales who feed on plankton and other wee oceanic tasties that they consume through their baleens, a specialised filter of keratin that frames their mouths.

There are 15 species of baleen whales. They inhabit all major oceans, in a wide band running from the Antarctic ice edge to 81°N latitude.

Humpback whales are rorquals, members of the Balaenopteridae family that includes the blue, fin, Bryde's, sei and minke whales. The rorquals are believed to have diverged from the other families of the suborder Mysticeti during the middle Miocene. While cetaceans were historically thought to have descended from mesonychids— which would place them outside the order Artiodactyla— molecular evidence supports them as a clade of even-toed ungulates — our dear Artiodactyla. Baleen whales split from toothed whales, the Odontoceti, around 34 million years ago.

It is one of the larger rorqual species, with adults ranging in length from 12–16 m (39–52 ft) and weighing around 25–30 metric tons (28–33 short tons). The humpback has a distinctive body shape, with long pectoral fins and a knobbly head. It is known for breaching and other distinctive surface behaviours, making it popular with whale watchers.

Both male and female humpback whales vocalize, but only males produce the long, loud, complex "song" for which the species is famous. Males produce a complex soulful song lasting 10 to 20 minutes, which they repeat for hours at a time. I imagine Gregorian Monks vocalizing their chant with each individual melody strengthening and complimenting that of their peers. All the males in a group produce the same song, which differed in each season. Its purpose is not clear, though it may help induce estrus in females and bonding amongst the males.

Humpback Whale, Megaptera novaeangliae
Found in oceans and seas around the world, humpback whales typically migrate up to 25,000 km (16,000 mi) each year. They feed in polar waters and migrate to tropical or subtropical waters to breed and give birth, fasting and living off their fat reserves. Their diet consists mostly of krill and small fish. Humpbacks have a diverse repertoire of feeding methods, including the bubble net technique.

Humpbacks are a friendly species that interact with other cetaceans such as bottlenose dolphins. They are also friendly and oddly protective of humans. You may recall hearing about an incident off the Cook Islands a few years back. In September of 2017, Nan Hauser was snorkelling and ran into a tiger shark. Two adult humpback whales rushed to her aid, blocking the shark from reaching her and pushing her back towards the shore. We could learn a thing or two from their kindness. We have not been as good to them as they have been to us.

Like other large whales, the humpback was a tasty and profitable target for the whaling industry. My grandfather and uncle participated in that industry out of Coal Harbour on northern Vancouver Island back in the 1950s. Six whaling stations operated on the coast of British Columbia between 1905 and 1976. Two of these stations were located in the Queen Charlotte Islands, one at Rose Harbour and the other at Naden Harbour. Over 9,400 large whales were taken from the waters around the Queen Charlotte Islands. The catch included blue whales, fin whales, sei whales, humpback whales, sperm whales and right whales. In the early years of the century, primarily humpback whales were taken. In later years, fin whales and sperm whales dominated the catch.

Whales were hunted off South Moresby in Haida Gwaii, on the north side of Holberg Inlet in the Quatsino Sound region. It was the norm at the time and a way to make a living, especially for those who had hoped to work in the local coal mine but lost their employment when it shut down.

My relatives participated in the hunt that nearly led to the extinction of our lovely Humpbacks before the process was banned back in the 1960s. The Coal Harbour Whaling Station closed in 1967. My grandfather Einar took to fishing and my uncle Harry lost his life when he slipped and fell over the side of the boat. He was crushed between the hull and a Humpback in rough seas.

Humpback populations have partially recovered to build their population up to 80,000 animals worldwide since the 1960s but entanglement in fishing gear, collisions with ships, and noise pollution continue to negatively impact the species. So be kind if you see them. Turn your engine off and see if you can hear their soulful cries echoing in the water.

I did up a video on Humpback Whales over on YouTube so you could see them in all their majesty. Here is the link: https://youtu.be/_Vbta7kQNoM

Friday, 19 March 2021

HOODED SEALS: CYSTOPHORA CRISTATA

Hooded seals, Cystophora cristata, are large phocid seals in the family Phocidae, who live in some of the chilliest places on Earth, from 47° to 80° N in latitude.

They frequent the eastern coast of North America north of Maine to the western tip of Europe, along the coast of Norway near Svalbard.

These skilled divers are mainly concentrated around Bear Island, Norway, Iceland, and northeast Greenland. In rare cases, we find them in the icy waters in Siberia. They usually dive depths of 600 m (1,968 ft) in search of fishy treats but can go as deep as 1000 m (3,280 ft) when needed. That is deep into the cold, dark depths of our oceans. Sunlight entering the sea may travel as deep as 1,000 m (3,280 ft) into the ocean under the right conditions, but there is rarely any significant light beyond 200 meters (656 ft).

Hooded seals have a sparse fossil record. One of the first fossils found was a Pliocene specimen from Anvers, Belgium discovered in 1876. In 1983 a paper was published claiming there were some fossils found in North America thought to be from Cystophora cristata. Of the three accounts, the most creditable discovery was from a sewer excavation in Maine, the northeasternmost U.S. state, known for its rocky coastline, maritime history and nature areas like the granite and spruce islands of Acadia National Park. A scapula and humeri were found among other bones and thought to date to the post-Pleistocene.

Of two other accounts, one was later reassigned to another species and the other left unsolved. (Folkow, et al., 2008; Kovacs and Lavigne, 1986; Ray, 1983)

The seals are typically silver-grey or white in colour, with black spots that vary in size covering most of the body. Hooded seal pups are known as "blue-backs" because their coats are blue-grey on the back with whitish bellies, though this coat is shed after 14 months of age when the pups moult.

Hooded seals live primarily on drifting pack ice and in deep water in the Arctic Ocean and North Atlantic. Although some drift away to warmer regions during the year their best survival rate is in colder climates. They can be found on four distinct areas with pack ice: near Jan Mayen Island (northeast of Iceland); off Labrador and northeastern Newfoundland; the Gulf of St. Lawrence; and the Davis Strait (off midwestern Greenland).

Hooded Seal and pup
Males appear to be localized around areas of complex seabeds, such as Baffin Bay, Davis Strait, and the Flemish Cap, while females concentrate their habitat efforts primarily on shelf areas, such as the Labrador Shelf.

Females reach the age of sexual maturity between 2 and 9 years old and it is estimated that most females give birth to their first young at around 5 years of age.

Males reach sexual maturity a little later around 4 to 6 years old but often do not mate until much later. Females give birth to one young at a time through March and April. The gestation period is 240 to 250 days. During this time the fetus - unlike those of other seals - sheds its lanugo (a covering of fine soft hair that is replaced by thicker pelage) in the uterus. These young are precocial and at birth are able to move about and swim with ease. They are independent and left to fend for themselves immediately after they have been weaned.

Hooded seals are known to be a highly migratory species that often wander long distances, as far west as Alaska and as far south as the Canary Islands and Guadeloupe. Prior to the mid-1990s, hooded seal sightings in Maine and the east Atlantic were rare but began increasing in the mid-1990s. From January 1997 to December 1999, a total of 84 recorded sightings of hooded seals occurred in the Gulf of Maine, one in France and one in Portugal. From 1996 to 2006, five strandings and sightings were noted near the Spanish coasts in the Mediterranean Sea. There is no scientific explanation for the increase in sightings and range of the hooded seal.

Cystophora means "bladder-bearer" in Greek and pays homage to this species' inflatable bladder septum on the heads of adult males. The bladder hangs between the eyes and down over the upper lip in the deflated state. In addition, the hooded seal can inflate a large balloon-like sac from one of its nostrils. This is done by shutting one nostril valve and inflating a membrane, which then protrudes from the other nostril. I was thinking of Hooded seals when contemplating the nasal bladders of Prosaurolophus maximum, large-headed duckbill dinosaurs, or hadrosaurid, in the ornithischian family Hadrosauridae. Perhaps both species used these bladders in a similar manner — to warn predators and attract mates.

The hooded seal is known for its uniquely elastic nasal cavity located at the top of its head, also known as the hood. Only males possess this display-worthy nasal sac, which they begin to develop around the age of four. The hood begins to inflate as the seal makes its initial breath prior to going underwater. It then begins to repetitively deflate and inflate as the seal is swimming. The purpose of this is acoustic signalling. It occurs when the seal feels threatened and attempt to ward off hostile species when competing for resources such as food and shelter. It also serves to communicate their health and superior status to both other males and females they are attempting to attract.

In sexually mature males, a pinkish balloon-like nasal membrane comes out of the left nostril to further aid it in attracting a mate. This membrane, when shaken, is able to produce various sounds and calls depending on whether the seal is underwater or on land. Most of these acoustic signals are used in an acoustic situation (about 79%), while about 12% of the signals are used for sexual purposes.

References: Ray, C. 1983. Hooded Seal, Cystophora cristata: Supposed Fossil Records in North America. American Society of Mammalogists, Vol. 64 No. 3: 509-512; Cystophora cristata, Hooded Seal", 2007; "Seal Conservation Society", 2001; Kovacs and Lavigne, 1986.

Thursday, 18 March 2021

PROSAUROLOPHUS MAXIMUS

Reconstruction of Prosaurolophus maximus
Prosaurolophus maximus was a large-headed duckbill dinosaur, or hadrosaurid, in the ornithischian family Hadrosauridae.

The most complete described Prosaurolophus maximus specimen had a skull an impressive 0.9 metres (3.0 ft) long that graced a skeleton about 8.5 metres (28 ft) long.

He had a small, stout, triangular crest in front of his eyes. The sides of the crest are concave, forming depressions. This crest grew isometrically — without changing in proportion — throughout the lifetime of each individual, leading one to wonder if Prosaurolophus had had a soft tissue display structure such as inflatable nasal sacs. We see this feature in hooded seals, Cystophora cristata, who live in the central and western North Atlantic today. Prosaurolophus maximus may have used their inflatable nasal sac for a display to warn a predator or to entice the ladies, attracting the attention of a female.

When this good looking fellow was originally described by Brown, Prosaurolophus maximus was known only from a skull and jaw. Half of the skull was badly weathered at the time of examination, and the level of the parietal was distorted and crushed upwards to the side. You can imagine that these deformations in preservation created some grief in the final description.

The different bones of the skull are easily defined with the exception of the parietal and nasal bones. Brown found that the skull of the already described genus Saurolophus was very similar overall, just smaller than the skull of Prosaurolophus maximus. The unique feature of a shortened frontal in lambeosaurines is also found in Prosaurolophus maximus, and the other horned hadrosaurines Brachylophosaurus, Maiasaura, and Saurolophus. Although they lack a shorter frontal, the genera Edmontosaurus and Shantungosaurus share an elongated dentary structure.

Prosaurolophus maximus, Ottawa Museum of Nature
Patches of preserved skin are known from two juvenile specimens, TMP 1998.50.1 and TMP 2016.37.1; these pertain to the ventral extremity of the ninth through fourteenth dorsal ribs, the caudal margin of the scapular blade, and the pelvic region. Small basement scales (scales that make up the majority of the skin surface), 3–7 millimetres (0.12–0.28 in) in diameter, are preserved on these patches - this is similar to the condition seen in other saurolophine hadrosaurs.

More uniquely, feature scales (larger, less numerous scales which are interspersed within the basement scales) around 5 millimetres (0.20 in) wide and 29 millimetres (1.1 in) long are found interspersed in the smaller scales in the patches from the ribs and scapula (they are absent from the pelvic patches). Similar scales are known from the tail of the related Saurolophus angustirostris (on which they have been speculated to indicate pattern), and it is considered likely adult Prosaurolophus would've retained the feature scales on their flanks like the juveniles.

Image: Three-dimensional reconstruction of Prosaurolophus maximus. Created using the skull reconstructions in the original description as reference. (Fig. 1 and 3 in Brown 1916). According to Lull and Wright (1942), the muzzle was restored too long in its original description. The colours and/or patterns, as with nearly all reconstructions of prehistoric creatures, are speculative. Created & uploaded to Wikipedia by Steveoc 86.

Wednesday, 17 March 2021

DR. DANNER: FOSSILS OF THE CHILLIWACK GROUP

In May 2001, Dr. Ted Danner, Professor Emeritus from UBC and my mentor gave a talk to the Vancouver Paleontological Society. For over fifteen years, we would meet for dinner on the third Thursday of every month. I would swing by to pick him up and we would head to his favourite restaurant for a meal and lively discussion.

Dinner was a delight of banter, stories and paleontological debates. Dr. Danner had a keen mind and a sharp wit. The world lost a truly beautiful soul when he passed away in 2012.

Wilbert R. Danner began teaching geology at UBC in 1954 and established the Beer-Pop Can-Bottle Deposit Refund Award in 1989 using proceeds from the return of bottles and cans collected on weekly scavenging treks on UBC’s Vancouver Campus.

Danner’s office was often full of cans ready to be taken to the recycling depot. He raised $46,000 from collected bottles and cans to support students before he passed away in 2012. He chose to name it the Beer-Pop Can-Bottle Deposit Refund Award to show that, over time, even small contributions can have a big impact.

“Ted taught UBC’s introductory geology course for many years,” says geologist and entrepreneur Ross Beaty, a former student of Danner and executor of his estate. “He was a quirky, enthusiastic professor who inspired many students to go into geoscience. What a wonderful legacy he’s now left for UBC and future generations of geologists.”

Danner’s bequest endows $320,000 for the Beer-Pop Can-Bottle Deposit Refund Award, which provides two awards annually to geology students who have demonstrated aptitude in fieldwork. Another $320,000 funds the newly established Ted Danner Memorial Entrance Bursary in Geology, provided to a student entering UBC enrolled in at least one geology course.

The estate also includes Danner’s extensive mineral collection, which now resides at UBC’s Pacific Museum of the Earth. It contains more than 2,000 specimens and is worth more than $500,000.

Beyond his annual award, Dr. Danner left a legacy in those he taught and mentored. Ted had a great fondness for the geology & fossils of the Chilliwack Group. A wonderful orator, Dr. Danner liked to reminisce about the Devonian quarry at Doaks Creek. He enjoyed hiking through the Late Mississippian limestone exposures on the east side of Red Mountain, where large crinoid columnals, corals and brachiopods have been found, sometimes partly silicified, on the weathered surfaces of the limestones and shales.

Further up the west side of Red Mountain at the Kendle Quarry there are Late Mississippian exposures where you can find fragments of brachiopods & goniatites. Dr. Danner would often tell the tale of Reginald A. Daly who published a series of maps in 1912 of areas along the International Boundary where he found fusulinids in the Chilliwack Valley. It seems the markers Daly originally mapped have been slowly tipping to the south, with Canada gaining a small advantage over the United States each year.

Tuesday, 16 March 2021

CRESTED BEAUTY: PARASAUROLOPHUS

Parasaurolophus is a genus of herbivorous ornithopod dinosaur that lived in what is now North America and possibly Asia during the Late Cretaceous Period, about 76.5–73 million years ago.

As a hadrosaurid, Parasaurolophus was a large bipedal/quadrupedal herbivore, eating plants with a sophisticated skull that permitted a grinding motion analogous to chewing. Its teeth were continually being replaced; they were packed into dental batteries containing hundreds of teeth, only a relative handful of which were in use at any time. It used its beak to crop plant material, which was held in the jaws by a cheek-like organ. Vegetation could have been taken from the ground up to a height of around 4 m (13 ft). As noted by the awesome Bob Bakker, lambeosaurines have narrower beaks than hadrosaurines, implying that Parasaurolophus and its relatives could feed more selectively than their broad-beaked, crestless counterparts.

Parasaurolophus was a hadrosaurid, part of a diverse family of Cretaceous dinosaurs known for their range of bizarre head adornments. This genus is known for its large, elaborate cranial crest, which at its largest forms a long curved tube projecting upwards and back from the skull. Charonosaurus from China, which may have been its closest relative, had a similar skull and potentially a similar crest. Visual recognition of both species and sex, acoustic resonance, and thermoregulation has been proposed as functional explanations for the crest. It is one of the rarer hadrosaurids, known from only a handful of well-preserved specimens.

Charles H. Sternberg
In 1921, Charles H. Sternberg recovered a partial skull (PMU.R1250) from what is now known as the slightly younger Kirtland Formation in San Juan County, New Mexico.

Sternberg was an American fossil collector and palaeontologist active in both fields from 1876 to 1928. He collected fossils for Edward Drinker Cope and Othniel C. Marsh, and for the British Museum, the San Diego Natural History Museum and other museums. He sent his specimen to Uppsala, Sweden, where Carl Wiman described it as a second species, P. tubicen, in 1931. The specific epithet is derived from the Latin tǔbǐcěn "trumpeter."

A second, nearly complete P. tubicen skull (NMMNH P-25100) was found in New Mexico in 1995. Using computed tomography scanning of the skull, Robert Sullivan and Thomas Williamson gave the genus a thorough analysis and interpretation of its anatomy and taxonomy, including various hypothesis for the functions of its crest. Williamson later published an independent review of the remains challenging the previous taxonomic placement.

John Ostrom described another good specimen (FMNH P27393) from New Mexico as P. cyrtocristatus in 1961. Ostrom was an American palaeontologist who revolutionized our understanding of dinosaurs in the 1960s. His find from New Mexico included a partial skull with a short, rounded crest, and much of the postcranial skeleton except for the feet, neck, and parts of the tail. Its specific name was derived from the Latin curtus "shortened" and cristatus "crested." The specimen was reported as being found at the top of the Fruitland Formation but was likely from the base of the overlying Kirtland Formation.

The range of this species was expanded in 1979, when David B. Weishampel and James A. Jensen described a partial skull with a similar crest (BYU 2467) from the Campanian-age Kaiparowits Formation of Garfield County, Utah. Since then, another skull has been found in Utah with the short/round P. cyrtocristatus crest morphology.



References:
  • Abel, Othenio (1924). "Die neuen Dinosaurierfunde in der Oberkreide Canadas". Jarbuch Naturwissenschaften (in German). 12 (36): 709–716. Bibcode:1924NW.....12..709A. doi:10.1007/BF01504818.
  • Bakker, R.T. (1986). The Dinosaur Heresies: New Theories Unlocking the Mysteries of Dinosaurs and their Extinction. William Morrow. p. 194. ISBN 978-0-8217-2859-8.
  • Benson, R.J.; Brussatte, S.J.; Anderson; Hone, D.; Parsons, K.; Xu, X.; Milner, D.; Naish, D. (2012). Prehistoric Life. Dorling Kindersley. p. 342. ISBN 978-0-7566-9910-9.
  • Brett-Surman, Michael K.; Wagner, Jonathan R. (2006). "Appendicular anatomy in Campanian and Maastrichtian North American hadrosaurids". In Carpenter, Kenneth (ed.). Horns and Beaks: Ceratopsian and Ornithopod Dinosaurs. Bloomington and Indianapolis: Indiana University Press. pp. 135–169. ISBN 978-0-253-34817-3.
  • Carr, T.D.; Williamson, T.E. (2010). "Bistahieversor sealeyi, gen. et sp. nov., a new tyrannosauroid from New Mexico and the origin of deep snouts in Tyrannosauroidea". Journal of Vertebrate Paleontology. 30 (1): 1–16. doi:10.1080/02724630903413032.



Monday, 15 March 2021

SOUTH AMERICAN TAPIR

South American tapir, Tapirus terrestris
This little sweetie with his brown fur stripped and dotted with bits of white is a South American tapir, Tapirus terrestris.

He is a relative of the rhinoceros and like his rhino cousins, he loves the water. They play, swim, dive, and use it to protect themselves from predators.

Their feet are specially designed for swimming and walking on muddy shores. Each of their front feet has four splayed toes, a bit like having a fin or snowshoe on your feet. Their back feet have a similar design but with three toes. They nap and hide in the forest during the day and then head out at night to munch on leaves, shoots, fruit, and other green goodies in the Amazon Rainforest and the River Basin in South America, east of the Andes.

We find fossil remains of tapir first appearing in the middle Eocene, 41 million years ago. While many families of perissodactyls achieved very high levels of diversity, there have never been more than a few species of tapirs. Tapirs are also morphologically conservative - their teeth and skeletons resemble those of early ceratomorphs, and some have referred to them as living fossils.

The skull is very specialized with many unique features related to the development of the proboscis. The four living species of tapirs use the prehensile proboscis to browse selectively on leaves, sprouts, and small branches, including aquatic plants and also ingest a great deal of fruit and seeds.

While modern tapir species are confined to tropical forests of South America and Asia, they originated and persisted for many millions of years in more northern regions, even during the ice ages, although their rarity as fossils suggests favourable habitats may have been scarce. Recently a huge fossil accumulation of late Miocene tapirs was discovered near Gray, Tennessee. It is the largest accumulation of fossil tapirs in the world and suggests that tapirs were once very common in some parts of North America.

Saturday, 13 March 2021

CONLINOCERAS TARRANTENSE

Previously Calycoceras Tarrantense, this ammonite is now called Conlinoceras tarrantense after J.P. Conlin, a famous early 20th century Texas fossil collector.

Ammonite expert Bill Cobban used this collection to describe many Texas Cretaceous ammonites species including this species from Tarrant County, Arlington, Texas.

He was a surveyor by training and kept incredibly detailed notes on the context of his fossils.

Conlin donated his collection to the USGS and we’ve learned much by studying it along with other specimens from the Lone Star State. Almost a quarter of Texas is covered by Cretaceous strata, much of it fossiliferous. If we stepped back 95 million years, the world and what we now call Texas, was a very different place.

95 million years ago, during the Late Cretaceous, a shallow seaway separated North America into separate eastern and western landmasses. We have a pretty complete picture in the fossil record of the western groups of species but relatively little in comparison for their cohorts in the east.

At the time this fellow was swimming our ancient seas, he was sharing the Earth with carnivorous dinosaurs, duck-billed dinosaurs, mammals, crocodilians, turtles, a variety of amphibians, prehistoric bony fish, oddly prolific sea cucumbers, various invertebrates and plants. Many of these sites are just being written up now and contain new species just being discovered.

During the Late Cretaceous Period, a shallow seaway separated North America into separate eastern and western landmasses. The Woodbine Formation in Texas preserves a rare fossil record of this time for the east, but many of these fossils are isolated and incomplete, making interpretations more difficult. Preliminary excavations at the AAS are providing hints at a more complete ecosystem, preserving similar patterns of change to what we see in the west.

The AAS contains an extraordinary diversity, abundance, and quality of fossil material, preserving one of the most complete terrestrial ecosystems known for this time period and area.

The AAS has a lot to tell us about Late Cretaceous life in the east. Over 2200 individual specimens have been found belonging to numerous groups including carnivorous dinosaurs, duck-billed dinosaurs, crocodilians, turtles, mammals, amphibians, sharks, bony fish, invertebrates, and plants.

Many of the fossils found here represent brand new species and studying these fossils will help to establish the geographic and environmental forces that shaped Cretaceous ecosystems in North America by providing a necessary comparison to the fossil record of the west.

Friday, 12 March 2021

KOREA: KIM CHI AND DINOSAUR TRACKS

Many years ago, I was touring with a Canadian/Norwegian company that sold log homes to Japanese and Korean buyers eager to have a taste of the traditional Scandinavian aesthetic mixed with West Coast style.

The opportunity to travel throughout Asia was very compelling and I am grateful to this day for those early trips as it has changed so much over the years. At the time, I was young and willing to work for my living allowance. No actual monies came my way, but my food, travel and accommodation were all taken care of.

I had always thought I chosen for my language skills. It was years later, upon looking at old photographs, that it dawned on me why I had been chosen. I would stand at the front of the room flipping large photographs of log homes during afternoon presentations. At the end of the presentation, I would bow and present a bottle of maple syrup to each of the honoured guests. Yup, I was a Canadian/Norwegian Vanna White doing much the same task, only in budding Japanese. Konichiwa!

This photograph was taken on a trip to Seoul, Korea, where we were meeting up with wholesalers and business folk eager to expand their networks. I spend a lovely afternoon visiting and enjoying a sizzling hot barbeque complete with beetles — meep, yes, beetles — and ample kimchi. Some of the staff agreed to join me outside for a photograph. As we posed, I thought how sweet the girls were in their traditional garb and how little they looked, delicate and certainly much shorter than me. Upon seeing the final photographs, however, I was shocked to realize I was shorter than all but one. Apparently, I am taller in my mind's eye.

While in Korea, I did get to see some of their impressive Cretaceous dinosaur trackways, one of which is now proposed as a World Heritage Site. South Korea also boasts impressive trackways of shorebirds and bountiful petrified wood. Sadly, I do not have any photographs of those finds to share with you. I have included coordinates for a few sites well worth a visit.

Fossil Sites of Korea: Uhang-ri, Hwangsan-myeon, Haenam-gun, Jeollanam-do: (34°45' N, 126°25' E) Bibong-ri, Deungnyang-myeon, Boseong-gun, Jeollanam-do: (34°45' N, 127°10' E) Sado-ri, Hwajeong-myeon, City of Yeosu, Jeollanam-do: (34°34'-37' N, 127°31'-34' E) Seoyu-ri, Buk-myeon, Hwasun-gun, Jeollanam-do: (35°09'51" N, 127°36'31" E) Deongmyeong-ri, Hai-myeon, Goseong-gun, Gyeongsangnam-do: (34°54' N, 128°08' E)

Thursday, 11 March 2021

EAST KOOTENAY REGION

The East Kootenay region on the south-eastern edge of British Columbia is a land of colossal mountains against a clear blue sky.

That is not strictly true, of course, as this area does see its fair share of rain and temperature extremes — but visiting in the summer every view is a postcard of mountainous terrain.

Rocks from deep within the Earth's crust underlie the entire East Kootenay region and are commonly exposed in the areas majestic mountain peaks, craggy rocky cliffs, glaciated river canyons, and in rock cuts along the highways. Younger Ice Age sediments blanket much of the underlying rock.

I've been heading to the Cranbrook and Fernie area since the early 1990s. My interest is the local geology and fossil history that these rocks have to tell. I'm also drawn to the warm and welcoming locals who share a love for the land and palaeontological treasures that open a window to our ancient past.

Cranbrook is the largest community in the region and is steeped in mining history and the opening of the west by the railway. It is also a stone's throw away from Fort Steele and the Lower Cambrian exposures of the Eager Formation. These fossil beds rival the slightly younger Burgess Shale fauna and while less varied, produce wonderful examples of olenellid trilobites and weird and wonderful arthropods nearly half a billion years old.

Labiostria westriopi, McKay Group
The Lower Cambrian Eager Formation outcrops at a few localities close to Fort Steele, many known since the early 1920s, and up near Mount Grainger near the highway.

Further east, the Upper Cambrian McKay Group near Tanglefoot Mountain is a palaeontological delight with fifteen known outcrops that have produced some of the best-preserved and varied trilobites in the province — many of them new species. The McKay Formation also includes Ordovician outcrops sprinkled in for good measure.

Other cities in the area and the routes to and from them produce other fossil fauna from Kimberley to Fernie and the district municipality of Invermere and Sparwood. This is an arid country with native grasslands and forests of semi-open fir and pine. Throughout there are a host of fossiliferous exposures from Lower Cretaceous plants to brachiopods. The area around Whiteswan Lake has wonderful large and showy Ordovician graptolites including Cardiograptus morsus and Pseudoclimacograptus angustifolius elongates — some of our oldest relatives. A drive down to Flathead will bring you to ammonite outcrops and you can even find Eocene fresh-water snails in the region.

The drive from Cranbrook to Fernie is about an hour and change through the Cambrian into the Devonian which flipflops and folds over revealing Jurassic exposures.

Fernie Ichthyosaur Excavation, 1916
The Crowsnest Highway into Fernie follows Mutz Creek. From the highway, you can see the Fernie Group and the site along the Elk River where an ichthyosaur was excavated in 1916.

The Fernie Formation is Jurassic. It is present in the western part of the Western Canada Sedimentary Basin in western Alberta and northeastern British Columbia.

It takes its name from the town of Fernie, British Columbia, and was first defined by W.W. Leach in 1914. The town of Fernie is rimmed by rugged mountains tipped with Devonian marine outcrops. In essence, all these mountains are upside down with the oldest layers flipped to the top and a good 180 million years older than those they sit upon.

Before they were mountains, these sedimentary rocks were formed as sediment collected in a shallow sea or inland basin. About 360 million years ago, the rocks that you see in Fernie today were down near the equator. They road tectonic plates, pushing northeast smashing into the coastline of what would become British Columbia. A little push here, shove there — compression and thrust faulting — and the rock was rolled over on its head — repeatedly. But that is how mountains are often formed, though not usually pushed so hard that they flip over. But still, it is a slow, relentless business.

Cretaceous Plant Material, Fernie, BC
Within Fernie, there are small exposures of Triassic and Jurassic marine outcrops. East of the town there are Cretaceous plant sites, and of course, the Jurassic 1.4-metre Titanites occidentalis ammonite up on Coal Mountain.

The regional district's dominant landform is the Rocky Mountain Trench, which is flanked by the Purcell Mountains and the Rocky Mountains on the east and west, and includes the Columbia Valley region. The southern half of which is in the regional district — its northern half is in the Columbia-Shuswap Regional District.

The regional district of Elk Valley in the southern Rockies is the entryway to the Crowsnest Pass and an important coal-mining area.

Other than the Columbia and Kootenay Rivers, whose valleys shape the bottomlands of the Rocky Mountain Trench, the regional districts form the northernmost parts of the basins of the Flathead, Moyie and Yahk Rivers. The Moyie and Yahk are tributaries of the Kootenay, entering it in the United States, and the Flathead is a tributary of the Clark Fork into Montana.

Photo One: Tyaughton Mountain, Mckay Group; Photo Two: Labiostria westriopi, Upper Cambrian McKay Group, Site ML (1998); John Fam Collection; Photo Three: Ichthyosaur Excavation, Fernie, British Columbia, 1916; Photo Four: Cretaceous Plant Fossils, east of Fernie towards Coal Mountain. The deeply awesome Guy Santucci as hand-model for scale.

Wednesday, 10 March 2021

LOWER CAMBRIAN EAGER FORMATION

This specimen of a mature olenellid trilobite, Wanneria dunnae, is from the Lower Cambrian Eager Formation of British Columbia.

He is from the Rifle Range outcrop near Cranbrook where you can find numerous fragments and complete specimens of the olenellid trilobites Ollenellus sp. and the larger, more robust Wanneria sp. you see here.

The site outcrops at a few locations as you head east out of Cranbrook towards Fort Steele.

The first trilobites were discovered with the building of the Kootenay Highway connecting Cranbrook to Fort Steele and beyond. Several other localities, including the outcrops at the Silhouette Rife Range — which is literally on a Rifle Range where folks go to shoot at things — is a shade older than the Middle Cambrian Burgess Shale but the fauna here is much less varied.

The site has been known and collected since the 1920s. Back in the day, fossil collecting was a family affair with folks heading out in their lightly coloured finery to picnic and surface collect the eroding exposures. Cranbrook local, Clement Hungerford Pollen was an engineer and avocational palaeontologist. He promoted collecting the exposures of the Eager Formation around 1921. As a pedigreed Englishman of considerable means, he had invested in the Kootenay Central Railway, revitalizing the town by opening up railway access within the region.

Olenellus ricei, Eager Formation
Olenellus is an extinct genus of redlichiid trilobites, with species of average size (about 5 centimetres or 2.0 inches long). He lived during the Botomian and Toyonian stages, Olenellus-zone, 522 to 510 million years ago, in what is currently North-America, part of the paleocontinent Laurentia.

These extinct arthropods are common in Early Cambrian rocks — 542 million to 521 million years old — and thus a useful guide fossil for the Early Cambrian.

Olenellus had a well-developed semi-circular head, large and crescentic eyes, and a poorly developed, small tail. Telltale features are his fifteen body segments with the third being much longer than the others. The fellow you see had a bit of his tail crushed as he turned to stone.

Trilobites were amongst the earliest fossils with hard skeletons. While they are extinct today, they were the dominant life form at the beginning of the Cambrian and it is what we find as the primary fossil fauna in the Eager Formation. The Eager Formation has produced many beautifully preserved Wanneria, abundant Olellenus and a handful of rare and treasured Tuzoia. The shale matrix lends itself to amazing preservation. The specimens of Wanneria from here are large. Some are up to thirteen centimetres long and ten centimetres wide. You find a mixture of complete specimens and head impressions from years of perfectly preserved moults.

Tuesday, 9 March 2021

HOW TO TELL FOSSIL BONE


If you are wondering if you have Fossil Bone, you’ll want to look for the telltale texture on the surface.

Fossil bone is also heavier than regular bone and will have some heft in your hand. This is because the bone has absorbed the yummy minerals from the material in which it was buried.

If you plan to have someone help you with identifying your find, it is best to take the specimen outside & photograph it in natural light. Take many photos from every angle. If you have the urge to take a video, move the lens very slowly so that all the wee details can be seen. With fossil bone, you will be able to see the different canals and webbed structure of the bone, sure signs that the object was of biological origin.

As my good friend Mike Boyd notes, without going into the distinction between dermal bone and endochondral bone — which relates to how they form or ossify — it is worth noting that bones such as the one illustrated here will usually have a layer of smooth (or periosteal) bone on the outer surface and spongy (or trabecular) bone inside.

Dinosaur Bone, Jurassic, Colorado, USA

The distinction can be well seen here in both photographs. The partial weathering away of the smooth external bone has resulted in the exposure of the spongy bone interiors. Geographic context is important, so knowing where it was found is very helpful for an ID.

Knowing the geologic context of your find can help you to figure out if you've perhaps found a terrestrial or marine fossil. Did you find any other fossils nearby?

Can you see pieces of fossil shells or remnants of fossil leaves? Things get tricky with erratics. That's when something has deposited a rock or fossil far from the place it originated. We see this with glaciers. The ice can act like a plough, lifting up and pushing a rock to a new location, then melting away to leave something out of context. If you do think you have found fossil bone, it is likely that your local government would like you to report it. You may have found something very significant. I very much hope you have.

Monday, 8 March 2021

HIKING TO THE FERNIE AMMONITE

The Fernie ammonite, Titanites occidentalis, from outcrops on Coal Mountain near Fernie, British Columbia, Canada.

This beauty is the remains of a carnivorous cephalopod within the family Dorsoplanitidae that lived and died in a shallow sea some 150 million years ago.

If you would like to get off the beaten track and hike up to see this ancient beauty, you will want to head to the town of Fernie in British Columbia close to the Alberta border.

Driving to the trail base is along an easy access road just east of town along Fernie Coal Road. There are some nice exposures of Cretaceous plant material on the north side (left-hand side) of the road as you head from Fernie towards Coal Creek. I recently drove up to Fernie to look at Cretaceous plant material and locate the access point to the now infamous Late Jurassic (Tithonian) Titanites (S.S. Buckman, 1921) site. While the drive out of town is on an easy, well-maintained road, the slog up to the ammonite site is a steep 3-hour push.

The first Titanites occidentalis was about one-third the size and was incorrectly identified as Lytoceras, a fast-moving nektonic carnivore. The specimen you see here is significantly larger at 1.4 metres (about four and a half feet) and rare in North America.

Titanites occidentalis, the Western Giant, is the second known specimen of this extinct fossil species. The first was discovered in 1947 in nearby Coal Creek by a British Columbia Geophysical Society mapping team. When they first discovered this marine fossil high up on the hillside, they could not believe their eyes — both because it is clearly marine at the top of a mountain and the sheer size of this ancient beauty.

In the summer of 1947, a field crew was mapping coal outcrops for the BC Geological Survey east of Fernie. One of the students reported finding “a fossil truck tire.” Fair enough. The similarity of size and optics are pretty close to your average Goodridge.

A few years later, GSC Paleontologist Hans Frebold described and named the fossil Titanites occidentalis after the large Jurassic ammonites from Dorset, England. The name comes from Greek mythology. Tithonus, as you may recall, was the Prince of Troy. He fell in love with Eos, the Greek Goddess of the Dawn. Eos begged Zeus to make her mortal lover immortal. Zeus granted her wish but did not grant Tithonus eternal youth. He did indeed live forever — ageing hideously. Ah, Zeus, you old trickster. It is a clever play on time placement. Dawn is the beginning of the day and the Tithonian being the latest age of the Late Jurassic. Clever Hans!

Hiking to the Fernie Ammonite

From the town of Fernie, British Columbia, head east along Coal Creek Road towards Coal Creek. The site is 3.81 km from the base of Coal Creek Road to the trailhead as the crow flies. I have mapped it here for you in yellow and added the wee purple GPS marker for the ammonite site proper. There is a nice, dark grey to black roadcut exposure of Cretaceous plants on the north side of the dirt road that is your cue to pull over and park.

You access the trailhead on the south side of the road. You'll need to cross the creek to begin your ascent. There is no easy way across the creek and you'll want to tackle this one with a friend when the water level is low.

The beginning of the trail is not clear but a bit of searching will reveal the trailhead with its telltale signs of previous hikers. This is a 2-3 hour moderate 6.3-kilometre hike up & back bush-whacking through scrub and fallen trees. Heading up, you'll make about a 246-metre elevation gain. You won't have a cellular signal up here but if you download the Google Map to your mobile, you'll have GPS to guide you.

If you're coming in from out of town, the closest airport is Cranbrook. Then it is about an hour and change to Fernie and another 15-minutes or so to the site.

You will want to leave your hammers with your vehicle (no need to carry the weight) as this site is best enjoyed with a camera. This is a site you will want to wear hiking boots to access. Know that these will get wet as you cross the creek. If you'd like to see the ammonite but are not keen on the hike, a cast has been made by fossil preparator Rod Bartlett and is on display at the Courtenay Museum in Courtenay, Vancouver Island, Canada. Fernie Ammonite Palaeo Coordinates: 49°29'04"N 115°00'49"W
